오토캐드 명령어 140 가지





오토캐드 명령어 140가지

1	APERTURE	Controls the size of the object snap target box 제어 객체 스넵 상자 크기 조절
2	ARC	Draws an arc of any size 호 그리는 명령어
3	AREA	Computes the area of a polygon, polyline or circle 다각형, 폴리라인과 같힌 닫힌 도형의 면적을 계산
4	ARRAY	Makes multiple copies of selected objects in a rectangular or circular pattern 선택 요소를 여거래의 복사본으로 생성할 때 사용
5	ATTDEF	Creates an Attribute Definition entity for textual information to be associated with a Block Definition 택스트 정보에 의한 속성 정의
6	ATTDISP	Controls the visibility of Attribute entities on a global basis 속성 개체의 가시성 제어
7	ATTEDIT	Permits editing of Attributes either globally or one by one 하나 하나의 속성을 편집 허가
8	ATTEXT	Extracts Attribute data from a drawing 추출 도면의 속성
9	AXIS	Displays a "ruler line" on the graphics monitor 그래픽에 Ruler line 을 표시
10	BASE	Specifies origin for subsequent insertion of the current drawing into another drawing 원점 지정
11	BLIPMODE	Controls display of marker blips for a point or entity selection 컨트롤 포인터 혹은 마커를 일시적으로 표시
12	BLOCK	Forms a compound object from a group of entities 선택 개체를 하나의 그룹으로 형성
13	BREAK	Erases part of an object, or splits it into two objects 선이나 객체의 선을 분할 할 때 사용하는 명령어
14	CHAMFER	Creates a chamfer at the intersection of two lines 두 라인의 교차점에 모따기 생성
15	CHANGE	Alters the location, size, orientation, or other properties of selected objects. Especially useful for text entities 선택 개체의 특성을 변경 (위치, 크기, 방향)
16	CHPROP	Modifies Properties of selection objects 선택 객체를 수정하여 등록
17	CIRCLE	Draws a arc of any size 호를 그릴때 사용하는 명령어
18	COLOR	Establish the color for subsequently drawn objects 순차적으로 객체 색상 설정
19	COPY	Draws a copy of selected objects 객체를 복사
20	DBLIST	Lists database information for every entity in the drawing 도면상에 있는 객체의 데이터베이스 정보 확인
21	DDATTE	Allows Attribute editing by means of a dialogue box 대화상자를 이용한 속성 편집
22	DDEMODES	Sets current layer, color, linetype, elevation, and thickness via dialogue box 대화상자를 이용하여 색상, 선종류, 높이, 두께 설정
23	DDLMODES	Sets layer properties via dialogue box 대화상자를 이용하여 레이어 속성 설정
24	DDRMODES	Sets drawing aids via dialogue box 대화상자를 이용하여 보조 셋트 지정
25	DDUCS	Displays a dialogue box for control of the current User Coordinate System 대화상자로 제어 시스템의 좌표를 표시
26	DELAY	Delays execution of the next command for a spedified time. Used with command scripts
27	DIM	Invokes dimensioning mode, permitting many dimension notatioins to be added to a drawing
28	DIMI	Allows one dimension notation to be added to a drawing, then returns to normal command mode
29	DIST	Finds distance between two points 두 점 사이의 거리를 측정
30	DIVIDE	Places markers along a selected object, dividing it inot a specified number of equal parts 선택된 객체의 균등 마커를 표기
31	DOUGHNUT OR DONUT	Draws rings with specified inside and outside diameters 내경 외경을 이용하여 원을 생성
32	DRAGMODE	Allows control of the dynamic specification ("Dragging") feature for all appropriate commands 드래그 모드 설정
33	DTEXT	Draws text items dynamically 동적 텍스트 항목
34	DVIEW	Defines parallel or visual perspective views dynamically
35	DXBIN	Inserts specially-coded binary files into a drawing
36	DXFIN	Loads a drawing interchange file
37	DXFOUT	Writes a drawing interchange file
38	EDGESURF	Constructs a 3D polygon mesh approximating a Coons surface patch (a bicubic surface interpolated between four adjoining edges)
39	ELEV	Sets elevation and extrusion thickness for subsequently drawn entities. Used in 3D visualizations (To be dropped in the next major update)
40	ELLIPSE	Draws ellipses using any of several specifications 타원형 객체 생성
41	END	Exits the Drawing Editor after saving the updated drawing 도면 업데이트 후 도면 편집기 종료
42	ERASE	Erases entities from the drawing 도면상의 선택한 객체를 삭제
43	EXPLODE	Shatters a Block or Polyline into its constituent parts 블럭이나 폴리라인의 객체를 해체
44	EXTEND	Lengthens a Line, Arc, or Polyline to meet another object 선이나 원의 객체 길이를 늘릴때 사용
45	FILES	Performs disk file utility tasks
46	FILL	Controls whether Solids, Traces, and wide Polylines are automatically filled on the screen and the plot output
47	FILLET	Constructs an arc of specified radius between two lines, arcs, or circles 필렛 형성 명령어
48	FILMROLI	Generates a file for rendering by Autoshade 렌더링을 위한 파일 생성
49	GRAPHSCR	Flips to the graphics display on single-screen systems. Used in commoand scripts and menus 단일 화면 표시 그래픽 디스플레이로 전환
50	GRID	Displays a grid of dots, at desired spacing, on the screen 화면에 격자를 표기
51	HANDLES	Assigns a unique, permanent number to each entity in a drawing 도면에서 객체별 고유 영구 번호를 할당
52	HATCH	Performs cross-hatching and pattern-filling 햇치 생성 명령어
53	`HELP OR'?	Displays a list of valid commands and data entry options or obtains help for a specific command 도움말
54	HIDE	Regenerates a 3D visualization with "hidden" lines removed hidden line 숨기기
55	ID	Displays the coordinates of a specified point
56	IGESIN	Loads an IGES interchange file
57	IGESOUT	Writes a IGES interchange file
58	INSERT	Insets a copy of a previously drawn part (object) into the current drawing 현대 조면에 사본 복사본을 붙여넣을때 사용하는 명령어
59	ISOPLANE	Selects the plane of an isometric grid to be the "current" plane for orthogonal drawing 선택 등각 그리드 형성
60	LAYER	Creates name drawing layers and assigns color and linetype properties to those layers 레이어 설정 명령어
61	LIMITS	Changes the drawing boundaries and controls checking of those boundaries 경계 확인과 컨트롤 변경
62	LINE	Draws straight lines of any length 선을 그릴때 사용하는 명령어
63	LINETYPE	Defines linetypes (sequences of alternating line segments and spaces), loads them from libraries, and sets the linetype for subsequently drawn objects 선종류 선택
64	LIST	Lists database information for selected objects 선택 객체의 데이터베이스 정보 확인
65	LOAD	Loads a file of user-defined shapes to be used with the SHAPE command 파일 로드
66	LTSCALE	Sets scale factor to be applied to all linetypes within the drawing 설정 축적 비율을 적용
67	MEASURE	Places markers at specified intervals along a selected object 마커
68	MENU	Loads a file of Drawing Editor commands into the menu areas (screen, pull-down, tablet, and button) 화면 풀다운, 버튼의 명령 에디터 영역
69	MINSERT	Inserts multiple copies of a Block in a rectangular pattern 직사각형 패턴 블럭 사본 삽입
70	MIRROR	Reflects designated entities about a user-specified axis 사용자가 지정한 축을 기준으로 대칭 객체 생성
71	MOVE	Moves designated entities to another location 객체 이동
72	MSLIDE	Makes a slide file from the current display
73	MULTIPLE	Causes the next command to repeat until cancelled
74	OFFSET	Allows the creation of offset curves and parallel lines 객체 띄우기 명령어
75	OOPS	Restores last erased entity
76	ORTHO	Constraints drawing so that only lines aligned with the grid can be entered
77	OSNAP	Enables points to be precisely located on reference points of exisitng objects SNAP 설정
78	PAN	Moves the display window
79	PEDIT (2D)	Permits editing of 2D polylines
80	PEDIT(3D)	Permits editing of 3D polylines
81	PEDIT (Mesh)	Permits editing of 3D polygon meshes:
82	PLAN	Puts the display in PLAN view (VPOINT 0,0,1) relative to either the current UCS, a specified UCS, or the World Coordinate System
83	PLINE	Draws two-dimensional polylines (connected line and arc segments, with optional width and taper
84	PLOT	Plots a drawing on a pen plotter 도면 출력시 사용하는 명령어
85	POINT	Draws single points
86	POLYGON	Draws regular polygon with the specified number of side
87	PRPLOT	Plots a drawing on a printer plotter
88	PURGE	Removes unused Blocks, text, styles, layers or linetypes from the drawing 사용하지 않는 블럭, 문자, 스타일 삭제
89	QTEXT	Enables text entities to be identified without drawing the text detail
90	QUIT	Exits the Drawing Editor and returns to AutoCAD's Main Menu, discarding any changes to the drawing Auto cad 종류 명령어
91	REDEFINE	Restores a built-in command deleted by UNDEFINE
92	REDO	Reverses the previous command even if it was U or UNDO 명령어 실행전 이전 화면으로 복귀
93	REDRAW	Refreshes or cleans up the current viewport 현재 화면 재 정렬
94	REDRAWALL	Redraws all viewports Viewports 변경
95	REGEN	Regenerates the current viewport 현재 viewport 재 생성
96	REGENALL	Regenerates all viewports 모든 viewports 재 생성
97	REGENAUTO	Controls automatic regeneration performed by other commands
98	RENAME	Changes the names associated with text styles, layers, linetypes, Blocks, Views, User Coordinate systems, and viewport configurations
99	RESUME	Resumes an interrupted command script
100	REVSURF	Creates a 3D ploygon mesh approximating a surgace of revolution, by rotating a curve around a selected axis
101	ROTATE	Rotates existing objects 객체 회전할 때 사용하는 명령어
102	RSCRIPT	Restarts a command script from the beginning
103	RULESURF	Creates a 3D polygon mesh approximating a ruled surface between two curves
104	SAVE	Updates the current drawing file without exiting the Drawing Editor 파일 저장
105	SCALE	Alters the size of existing objects 스케일 적용
106	SCRIPT	Executes a command script
107	SELECT	Groups objects into a selection.set for use in subsequent commands
108	SETVAR	Allows you to display or change the value of system variables
109	SH	Allows access to internal PC - DOS/MS-DOS commands
110	SHAPE	Draws pre-defined shapes
111	SHELL	Allows access to other programs while running AutoCAD
112	SKETCH	Permits free-hand sketching
113	SNAP	Specifies a "round-off" interval for digitizer point entry so entities can be placed at precise locations easily
114	SOLID	Draws filled-in polygons
115	STATUS	Displays drawing statistics & modes
116	STRETCH	Allows you to move a portion of a drawing while retaining connections to other parts of the drawing 객체를 늘리거나 줄일 때 사용하는 명령어
117	STYLE	Creates named text styles, with user-selected combinations of font, mirroring, obliquing and horizontal scaling
118	TABLET	Aligns the digitzing tablet with coordinates of a paper drawing to accurately copy it with AutoCAD
119	TABSURF	Creates a polygon mesh aproximating a general tabulated surface defined by a path and a direction verctor
120	TEXT	Draws text characters of any size, with selected styles 문자를 입력할 때 사용하는 명령어
121	TEXTSCR	Flips to the text display on single-screen systems. Used in command scripts and menus
122	TIME	Displays drawing creation and update times, and permits control of an elapsed timer 도면 생성 시간을 업데이트
123	TRACE	Draws solid lines of specified width
124	TRIM	Erased the portions of selected entities that cross a specified boundary 객체를 잘라내기 할 때 사용
125	U	Reverses the effect of the previous command
126	UCS	Defines or modifies the current User Coordinate System
127	UCSICON	Controls visibility and placement of the User Coordinate System icon, which indicates the origin and orientation of the current UCS. The options normally affect only the current view port.
128	UNDEFINE	Deletes the definition of a built-in AutoCAD command
129	UNDO	Reverses the effect of multiple commands, and provides control over the "UNDO" facility
130	UNITS	Selects coordinate and angle display formats & precision 단위 편집기 명령어
131	VIEW	Saves the current graphics display as a Named View, or restores a saved view ot the display
132	VIEWPORTS or VPORTS	Divides the AutoCAD's graphics display into multiple viewports, each of which may contain a different view of the current drawing
133	VIEWRES	Allows you to control the precision and speed of Circle and Arc drawing on the monitor by specifying the number of sides in a Circle
134	VPOINT	Selects the viewpoint for a 3D visualizaiton
135	VSLIDE	Displays a previously-created slide file
136	WBLOCK	Writes selected entities to a disk file
137	ZOOM	Enlarges or reduces the display of the drawing
138	3DFACE	Draws three-dimensional plane selections
139	3DMESH	Defines a three-dimensional polygon mesh by specifying its size (in terms of M and N) and the location of each vertex in the mesh
140	3DPOLY	Creates a three-dimensional polyline
