ASTM Piping 관련 Code 27가지와 KS, JIS, DIN 비교표







ASTM 배관 관련 Code 28가지와 이를 대체할 수 있는 KS, JIS, DIN 규격을 순서대로 나열해 봤습니다. 특정 Code를 완전히 다른 Code와 동등한 것으로 취급하는 것이 아닌 비교 가능하고 대체 가능하다는 인식에서 출발하는 것이 중요합니다. 가령 ASTM A53B는 D4301 GC30과 Equivalent(동일) 하다는 것은 잘못된 인식입니다. 국가별 Code 는 100% 동일하지 않다는 것과 Code 를 비교한다는 것은 대체(Substitute) 가능한 Code 를 찾는다는 데 그 의미가 있습니다.



아래 테이블을 참고하는 방법은 좌측 부터 ASTM을 기준으로 하여 KS, JIS, DIN 규격 순으로 대체 비교 가능한 Code 를 나열하였습니다. ASTM 배관 관련 Code 자료를 찾아보면서 확인한 내용은 일부 ASTM 배관 Code 들이 중단되거나 철회된 것도 있고 KS, JIS 에는 비교 Data 가 없다는 것 입니다.





1. ASTM A53 Welded and Seamless Steel Pipe, Black and Galvanized



ASTM	KS	JIS	DIN
Type S.Gr.A	D 4301 GC 15	G 5501 FC 15	DIN 1691 GG-15
Type S.Gr.B	D 4301 GC 20	G 5501 FC 20	DIN 1691 GG-20
Type E.Gr.A	D 4301 GC 25	G 5501 FC 25	DIN 1691 GG-25
Type E.Gr.B	D 4301 GC 30	G 5501 FC 30	DIN 1691 GG-30





2. ASTM A106 Seamless CS Pipe for High Temp. Services



Gr.  A	D 3564 SPPH 38	G 3455 STS 38	DIN 1629 St 35.4
	D 3570 SPHT 38-S	G 3456 STPT 38-S	DIN 17175 St 35.8
Gr.  B	D 3564 SPPH 42	G 3455 STS 42	DIN 1629 St 45.4
	D 3570 SPHT 42-S	G 3456 STPT 42-S	DIN 17175 St 45.8
Gr.  C	D 3564 SPPH 49	G 3455 STS 49	DIN 1629 St 52.4
			SEW 610-17Mn4
			SEW 610-19Mn5
	D 3570 SPHT 49-S	G 3456 STPT 49-S	DIN 17175 St.45.8
			SEW 610-17Mn4
			SEW 610-19Mn5







3. ASTM A120 Black and Hot Dipped Zinc coated (Galvanized) welded and seamless pipe for ordinary use



**ASTM A120은 1987년에 중단되었으며 A53로 대체되었습니다.







4. ASTM A134 Electric fusion welded steel plate pipe (Sizes > 16” NB)
A134	D 3583 SPW 41	G 3457 STPY 41	DIN 1626 St 33





5.ASTM A135 electric resistance welded pipe
Gr. A	-	G 3454 STPG370	1626 St37.0
Gr. B	-	G 3454 STPG370	1626 St44.0





6. A155 Electric fusion welded steel pipe for high temperature service

**ASTM A155는 1978년에 중단되었으며 A671로 대체되었습니다





7. ASTM A312 Seamless and welded austenitic stainless steel pipes
Gr.  TP 304	D 3576  STS 304TP	G 3459  SUS 304TP	DIN 2462  5CrNi 18 9  SEW 680 5CrNi 18 10
Gr.  TP 304H	D 3576  STS 304HTP	G 3459  SUS 304HTP	-
Gr.  TP 304L	D 3576  STS 304LTP	G 3459  SUS 304LTP	DIN 2463  2CrNi 18 9
Gr.  TP 309	D 3576  STS 309TP	G 3459  SUS 309TP	-
Gr.  TP 310	D 3576  STS 310STP	G 3459  SUS 310STP	-
Gr.  TP 316	D 3576  STS 310STP	G 3459  SUS 316TP	DIN 2462 5CrNiMo 18 10  DIN 2462 5CrNiMo 18 12
Gr.  TP 316H	D 3576  STS 316TP	G 3459  SUS 316HTP	-
Gr.  TP 316L	D 3576  STS 316HTP	G 3459  SUS 316LTP	DIN 2462 2CrNiMo 18 10 DIN 2462 2CrNiMo 18 12
Gr.  TP 321	D 3576  STS 321TP	G 3459  SUS 321TP	SEW 680 10CrNiTi 18 10 DIN 2462 10CrNiTi 18 9
Gr.  TP 321H	D 3576  STS 321HTP	G 3459  SUS 321HTP	-
Gr.  TP 347	D 3576  STS 347TP	G 3459  SUS 347TP	DIN 2462 10CrNiNb13 10 SEW 680 10CrNiNb18 9
Gr.  TP 347H	D 3576  STS 347HTP	G 3459  SUS 347HTP	DIN 2462 10CrNiNb13  9 SEW 670  3CrNiNb16 13



9. ASTM A335 Seamless ferritic alloy steel pipe for high temperature service
Gr.  P1	D 3573  SPA 23	G 3458  STPA 12	DIN 17175  15Mo3
Gr.  P5	D 3573  SPA 23	G 3458  STPA 25	VdT ÜVWb1.1207
Gr.  P9	D 3573  SPA 23	G 3458  STPA 26	Wst.-Nr1.7386 12CrMo44
Gr.  P11	D 3573  SPA 23	G 3458  STPA 23	DIN 17175 13CrMo44
Gr.  P12	D 3573  SPA 23	G 3458  STPA 22	DIN 17175 13CrMo44
Gr.  P22	D 3573  SPA 23	G 3458  STPA 24	DIN 17175 10CrMo9 10







10. ASTM A358 Electric fusion welded austenitic chrome- nickel steel pipe for high temperature service



Grade 304	STS304TPY	SUS304TPY	X5CrNi 18 9 /1.4301
Grade 310	STS310STPY	SUS310STPY	X12CrNi 25 21 /1.4845
Grade 316	STS316TPY	SUS316TPY	X5CrNiMo 18 10 /1.4401
Grade 321	STS321TPY	SUS321TPY	X10CrNiTi 18 9 /1.4541
Grade 347	STS347TPY	SUS347TPY	X10CrNiNb 18 9 /1.455







11. ASTM A376 Seamless austenitic steel pipe for high temperature central station service



TP 304 (18Cr-8Ni)	-	G 3459 SUS304TP	17459 E X6CrNi1811
TP 304H (18Cr-8Ni)	-	G 3459 SUS304HTP	-
TP 316 (16Cr-12Ni-2Mo)	-	G 3459 SUS316TP	17458 X5CrNiMo17122
TP 316H (16Cr-12Ni-2Mo)	-	G 3459 SUS316HTP	17459 E X6CrNiMo1713
TP 321 (18Cr-10Ni-Ti)	-	G 3459 SUS321TP	17458 X6CrNiTi810
TP 321H (18Cr-10Ni-Ti)	-	G 3459 SUS321HTP	-
TP 347 (18Cr-10Ni-Cb)	-	G 3459 SUS347TP	17458 X6CrNiNb1810
TP 347H (18Cr-10Ni-Cb)	-	G 3459 SUS347HTP	-









12. ASTM A409 Welded large diameter austenitic steel pipe for corrosive or high temperature service



TP 304 (18Cr-8Ni)	-	G 3468 SUS304TPY	17457 X5CrNi810
TP 304L	-	G 3463 SUS304LTPY	17457 X2CrNi1911
TP 316 (16Cr-12Ni-2Mo)	-	G 3468 SUS316TPY	17457 X5CrNiMo17122
TP 316L	-	G 3468 SUS316LTPY	17457 X2CrNiMo17132
TP 321 (18Cr-10Ni-Ti)	-	G 3468 SUS321TPY	17457 X6CrNiTi1810
TP 347 (18Cr-10Ni-Cb)	-	G 3468 SUS347TPY	17457 X6CrN iNb1810







13. ASTM A426 Centrifugally cast ferritic alloy steel pipe for high temperature service



Gr.  CP 1	SCPH 11-CF	SCPH 11-CF	-
Gr.  CP12	SCPH 21-CF	SCPH 21-CF	-
Gr.  CP22	SCPH 32-CF	SCPH 32-CF	-
Gr.  CPCA15	SSC 1 SSC  1-CF	SCS-1 SCS1-CF	DIN 17445G 12Cr14







14. ASTM A430 Austenitic steel forged and bored pipe for high temperature service



Gr.  FP304	STS 304-TP	SUS 304 TP-SC,-SH	DIN 2462 5CrNi8 9  SEW 680 5CrNi18 10
Gr.  FP304H	STS 304-HTP	SUS 304HTP	DIN 2462 5CrNiMo18 10  DIN 2462 5CrNiMo18 12
Gr.  FP316	STS 316-TP	SUS 316TP
Gr.  FP316H	STS 316-HTP	SUS 316HTP
Gr.  FP321	STS 321-TP	SUS 321TP	DIN 2452 10CrNiTi18 9  SEW 680 10CrNiTi8 10
Gr.  FP321H	STS 321-HTP	SUS 321HTP
Gr.  FP347	STS 347-TP	SUS 347TP	DIN 2462 10CrNiNb18 9  SEW 680 10CrNiNb1810







15. ASTM A451 Centrifugally cast austenitic steel pipe for high temperature service



Grade CPF 8	-	-	G-X6CrNi 18 9 / 17445 / 1.4308
Grade CPF 8C	-	-	G-X7CrNiNb 18 9 / 17445 / 1.4552
Grade CPF 8M	-	-	G-X6CrNiMo 18 9 / 17445 / 1.4408
Grade CPK 20	-	-	G-X15CrNi 25 20 / 17445 / 1.4840





16. ASTM A452 Centrifugally cast austenitic steel cold wrought pipe for high temperature service

*No information





17. ASTM A524 Seamless carbon steel pipe for atmospheric and low temperature services



Gr.  Ⅰ	SPPS38-S	STPG38-S	DIN1629 St-35
	SPPH38	STS38	DIN1629 St-35,4
Gr. Ⅱ	SPPS42-S	STPG42-S	DIN1626 St-42
			DIN1626 St-42-2
	SPPH42	STS42	DIN1626st-45,4





18. ASTM A587 Electric welded low carbon steel pipe for the chemical industry



A587	-	G 3454 STPG370	1626 St37.0



19. ASTM A671 Electric fusion welded steel pipe for atmospheric and low temperature service (Sizes > 16” NB)



CA55 A285 Gr C	-		-
CB60 A515 Gr 60	-	JPI-SB42	-
CB70 A515 Gr 65	-	JPI-SB46	-
CB70 A515 Gr 70	-	JPI-SB49	-
CC60 A516 Gr 60	-	JPI-SLA24B	-
CC65 A516 Gr 65	-	JPI-SLA33B	-
CD70 A537 CL 1	-	-	-
CE55 A442 Gr 55	-	-	-
CE60 A442 Gr 60	-	JPI-SPV24	-
CF70 A203 Gr B	-	-	-
CF71 A203 Gr E	-	JPI-SL3N28	-
CK75 A299	-	-	-





20. ASTM A672 Electric fusion welded steel pipe for high pressure service at moderate temperature services (Sizes > 16" NB)



A55 A285 Gr C	-	JPI-SB42	-
B55 A515 Gr 55	-	-	-
B60 A515 Gr 60	-	JPI-SB42	-
B65 A515 Gr 65	-	JPI-SB46	-
B70 A515 Gr 70	-	JPI-SB49	-
C55 A516 Gr 55	-	-	-
C60 A516 Gr 60	-	JPI-SLA24B	-
C65 A516 Gr 65	-	JPI-SLA33B	-
C70 A516 Gr 70	-	-	-
D70 A537 CL 1	-	-	-
E55 A442 Gr 55	-	-	-
E60 A442 Gr 60	-	JPI-SPV24	-
L65 A204 Gr A	-	JPI-SB46M	-
L70 A204 Gr B	-	JPI-SB49M	-
L75 A204 Gr C	-	-	-
N75 A299	-	-	-





23. ASTM A691 Carbon and alloy steel pipe, electric fusion welded for high pressure service at high temperatures (Sizes > 16" NB)



CM-65 A204 Gr A	-	JPI-SB46M	-
CM-70 A204 Gr B	-	JPI-SB49M	-
CM-75 A204 Gr C	-	-	-
CMSH-70 A537 CL 1	-	-	-
CMS-75 A299	-	-	-
½ Cr A337 Gr 2 CL 1	-	-	-
1 Cr A387 Gr 12 CL 1	-	JPI-SCMV2	-
1-1/4 Cr A387 Gr 11 CL1	-	JPI-SCMV3	-
2-1/4 Cr A387 Gr 22 CL1	-	JPI-SCMV4	-
5 Cr A387 Gr 5 CL 1	-	JPI-SCMV6	-





24. ASTM A731 Seamless and welded ferritic stainless steel pipe
** Withdrawn 1995y





24. ASTM A731 Seamless and welded ferritic stainless steel pipe
** Withdrawn 1995y





25. ASTM A790 Seamless and welded ferritic/ austenitic

A790

-

-

1.4539





26. ASTM A813 Single or double welded austenitic stainless steel pipe
** No information





27. ASTM A814 Cold worked welded austenitic stainless steel Pipe
** No information
